Strength and strain sensors-

Force and Strain Sensors

.

Showing 37-48 of 90 item(s)
Sort by:
Best sellers Relevance Name, A to Z Name, Z to A
Showing 37-48 of 90 item(s)

Active filters

PCB-(M)216B
1

PCB-(M)216B

  • Force measuring washer with charge output,
  • Measuring range 356 kN
  • Sensitivity 4.05 pC/N,.
  • Upper frequency limit 40,000 Hz,.
  • 10-32 socket side
      • PCB-(M)260A02
      0

      PCB-(M)260A02

    • Triaxial ICP® power sensor,
    • Measuring range (Z axis) 4.45 kN,
    • Measuring range (X - and Y-axes) 4.45 kN,
    • Sensitivity (Z-axis) 0.56 mV / N,
    • Sensitivity (X - and Y-axes) 1.12 mV / N,
    • Frequency range (Z axis) 0.01 … 90,000 Hz,
    • Frequency range (X - and Y-axes) 0.001 … 90,000 Hz,
    • 4-pin female connector on the side
        • PCB-(M)204C
        1

        PCB-(M)204C

      • ICP® power measurement washer,
      • Measuring range 178 kN,
      • Sensitivity 27 mV / kN,
      • Frequency range 0.0003 … 55,000 Hz,
      • 10-32 female connector on the side
          • PCB-218C
          0

          PCB-218C

        • Universally applicable force sensor with charge output,
        • Range 2,224 … 22,240 N,
        • Sensitivity 4.05 pC/N,
        • Upper limit frequency 36,000 Hz,
        • 10-32 female connector on the side
            • PCB-(M)260A03
            0

            PCB-(M)260A03

          • Triaxial ICP® power sensor,
          • Measuring range (Z axis) 44.5 kN,
          • Measuring range (X - and Y-axes) 17.8 kN,
          • Sensitivity (Z-axis) 0.06 mV / N,
          • Sensitivity (X - and Y-axes) 0.28 mV / N,
          • Frequency range (Z axis) 0.01 … 39,000 Hz,
          • Frequency range (X - and Y-axes) 0.001 … 39,000 Hz,
          • 4-pin female connector on the side
              • PCB-(M)205C
              0

              PCB-(M)205C

            • ICP® power measurement washer,
            • Measuring range 267 kN,
            • Sensitivity 18 mV / kN,
            • Frequency range 0.0003 … 50,000 Hz,
            • 10-32 female connector on the side
                • PCB-(M)221B01
                0

                PCB-(M)221B01

              • ICP® force measuring element,
              • Measuring range 44.5 N,
              • Sensitivity 112 mV / N,
              • Frequency range 0.01 … 15,000 Hz,
              • 10-32 female connector on the side
                  • PCB-(M)260A11
                  0

                  PCB-(M)260A11

                • Triaxial force sensor with charge output,
                • Measuring range (Z axis) 4.45 kN,
                • Measuring range (X - and Y-axes) 2.22 kN,
                • Sensitivity (Z-axis) 3.4 pC/N,.
                • Sensitivity (X - and Y-axes) 7.2 pC/N,.
                • Upper frequency limit 90,000 Hz,.
                • Three 10-32 connectors on the side
                    • PCB-200B01
                    1

                    PCB-200B01

                  • ICP® sensor for power measurement,
                  • Measuring range 44.5 N,
                  • Sensitivity 112 mV / N,
                  • Frequency range 0.01 … 75,000 Hz,
                  • 10-32 female connector on the side
                      • PCB-(M)206C
                      1

                      PCB-(M)206C

                    • ICP® power measurement washer,
                    • Measuring range 356 kN,
                    • Sensitivity 13,5 mV / kN,
                    • Frequency range 0.0003 … 40,000 Hz,
                    • 10-32 female connector on the side
                        • PCB-(M)221B02
                        1

                        PCB-(M)221B02

                      • ICP® force measuring element,
                      • Measuring range 445 N,
                      • Sensitivity 11,2 µV / N,
                      • Frequency range 0.006 … 15,000 Hz,
                      • 10-32 female connector on the side
                          • PCB-(M)260A12
                          1

                          PCB-(M)260A12

                          • Triaxial force sensor with charge output,
                          • Measuring range (Z axis) 4.45 kN,
                          • Measuring range (X - and Y-axes) 4.45 kN,
                          • Sensitivity (Z-axis) 3.4 pC/N,.
                          • Sensitivity (X - and Y-axes) 7.2 pC/N,.
                          • Upper frequency limit 90,000 Hz,.
                          • Three 10-32 connectors on the side
