Strength and strain sensors-

Force and Strain Sensors

.

Showing 25-36 of 90 item(s)
Sort by:
Best sellers Relevance Name, A to Z Name, Z to A
Showing 25-36 of 90 item(s)

Active filters

PCB-(M)261A12
0

PCB-(M)261A12

  • Triaxial strength measuring element with charge output,
  • Measuring range (Z axis) 4.45 kN,
  • Measuring range (X - and Y-axes) 4.45 kN,
  • Sensitivity (Z-axis) 3.4 pC/N,.
  • Sensitivity (X - and Y-axes) 7.2 pC/N,.
  • Upper frequency limit 10,000 Hz,.
  • Three 10-32 connectors on the side
      • PCB-(M)261A13
      1

      PCB-(M)261A13

    • Triaxial strength measuring element with charge output,
    • Measuring range (Z axis) 44.5 kN,
    • Measuring range (X - and Y-axes) 17.7 kN,
    • Sensitivity (Z-axis) 3.4 pC/N,.
    • Sensitivity (X - and Y-axes) 7.2 pC/N,.
    • Upper frequency limit 10,000 Hz,.
    • Three 10-32 connectors on the side
        • PCB-(M)203B
        0

        PCB-(M)203B

      • ICP® power measurement washer,
      • Measuring range 89 kN,
      • Sensitivity 56 mV / kN,
      • Frequency range 0.0003 … 60,000 Hz,
      • 10-32 female connector on the side
          • PCB-(M)216B
          0

          PCB-(M)216B

        • Force measuring washer with charge output,
        • Measuring range 356 kN
        • Sensitivity 4.05 pC/N,.
        • Upper frequency limit 40,000 Hz,.
        • 10-32 socket side
            • PCB-(M)260A02
            0

            PCB-(M)260A02

          • Triaxial ICP® power sensor,
          • Measuring range (Z axis) 4.45 kN,
          • Measuring range (X - and Y-axes) 4.45 kN,
          • Sensitivity (Z-axis) 0.56 mV / N,
          • Sensitivity (X - and Y-axes) 1.12 mV / N,
          • Frequency range (Z axis) 0.01 … 90,000 Hz,
          • Frequency range (X - and Y-axes) 0.001 … 90,000 Hz,
          • 4-pin female connector on the side
              • PCB-(M)204C
              0

              PCB-(M)204C

            • ICP® power measurement washer,
            • Measuring range 178 kN,
            • Sensitivity 27 mV / kN,
            • Frequency range 0.0003 … 55,000 Hz,
            • 10-32 female connector on the side
                • PCB-218C
                0

                PCB-218C

              • Universally applicable force sensor with charge output,
              • Range 2,224 … 22,240 N,
              • Sensitivity 4.05 pC/N,
              • Upper limit frequency 36,000 Hz,
              • 10-32 female connector on the side
                  • PCB-(M)260A03
                  0

                  PCB-(M)260A03

                • Triaxial ICP® power sensor,
                • Measuring range (Z axis) 44.5 kN,
                • Measuring range (X - and Y-axes) 17.8 kN,
                • Sensitivity (Z-axis) 0.06 mV / N,
                • Sensitivity (X - and Y-axes) 0.28 mV / N,
                • Frequency range (Z axis) 0.01 … 39,000 Hz,
                • Frequency range (X - and Y-axes) 0.001 … 39,000 Hz,
                • 4-pin female connector on the side
                    • PCB-(M)205C
                    0

                    PCB-(M)205C

                  • ICP® power measurement washer,
                  • Measuring range 267 kN,
                  • Sensitivity 18 mV / kN,
                  • Frequency range 0.0003 … 50,000 Hz,
                  • 10-32 female connector on the side
                      • PCB-(M)221B01
                      0

                      PCB-(M)221B01

                    • ICP® force measuring element,
                    • Measuring range 44.5 N,
                    • Sensitivity 112 mV / N,
                    • Frequency range 0.01 … 15,000 Hz,
                    • 10-32 female connector on the side
                        • PCB-(M)260A11
                        0

                        PCB-(M)260A11

                      • Triaxial force sensor with charge output,
                      • Measuring range (Z axis) 4.45 kN,
                      • Measuring range (X - and Y-axes) 2.22 kN,
                      • Sensitivity (Z-axis) 3.4 pC/N,.
                      • Sensitivity (X - and Y-axes) 7.2 pC/N,.
                      • Upper frequency limit 90,000 Hz,.
                      • Three 10-32 connectors on the side
                          • PCB-200B01
                          1

                          PCB-200B01

                        • ICP® sensor for power measurement,
                        • Measuring range 44.5 N,
                        • Sensitivity 112 mV / N,
                        • Frequency range 0.01 … 75,000 Hz,
                        • 10-32 female connector on the side
