Industrial Vibration Sensors

.

Showing 25-36 of 205 item(s)
Showing 25-36 of 205 item(s)

Active filters

PCB-EX611A20

  • Vibration sensor with charge output,
  • With ATEX approval,
  • Continuous use temperature up to 650 ° C,
  • With through-holes
  • Measuring range 200 g,
  • Sensitivity 10 pC/g,.
  • Upper frequency limit 3,700 Hz,
  • Integrated hardline cable, length 3 m,
    ending on LEMO connectors

PCB-(M)639A91

  • Triaxial industrial ICP® vibration sensor,
  • With drill through,
  • Measurement range 50 g,
  • Sensitivity 100 mV/g,
  • Frequency range 0.5... 10,000 Hz,
  • Frequency response calibration,
  • M12 connector on the side

ICP® Beschleunigungssensor-Kit: PCB-(M)603C91 & 507QSXXXBZ

  • IP69K compliant ICP® acceleration sensor Kit, compact design,
  • Aligned on high hygienic requirements in food production.
  • Consisting of sensor PCB-(M)603C91 & cable 507QSXXXBZ,.
  • Industrial ICP® vibration sensor,
  • Measurement range 50 g,
  • Sensitivity 100 mV/g,
  • Frequency range 0.5... 10,000 Hz,
  • One-point calibration at 100 Hz,
  • M12 socket top

ICP® Beschleunigungssensor-Kit: PCB-(M)602D91 & 507QSXXXBZ

  • IP69K compliant ICP® acceleration sensor Kit, side mounted,
  • Aligned on the hygienic requirements in food production.
  • Sensor PCB-(M)602D91 & cable 507QSXXXBZ,
  • Industrial ICP® vibration sensor,
  • With drill through,.
  • Measurement range 50 g,
  • Sensitivity 100 mV/g,
  • Frequency range 0.5... 8,000 Hz,
  • One-point calibration at 100 Hz,
  • M12 connector

ICP® Beschleunigungssensor-Kit: PCB-(M)601A92 & 507QSXXXBZ

  • IP69K compliant ICP® acceleration sensor Kit, low-noise,
  • Aligned on high hygienic requirements in food production.
  • Consisting of sensor PCB-(M)601A92 & cable 507QSXXXBZ,.
  • Industrial ICP® vibration sensor,
  • Measuring range 10 g,
  • Sensitivity 500 mV / g,.
  • Frequency range 0.17... 10,000 Hz,
  • One-point calibration at 100 Hz,
  • M12 socket top

PCB-VO(M)625B01

  • Industrial ICP® vibration sensor,
  • With vibration velocity output
  • With through hole,
  • Measuring range 1.27 m/s,
  • Sensitivity 3.9 mV/(mm/s),
  • Frequency range 1.5 … 6,000 Hz,
  • Frequency response calibration,
  • 2-pin female connector on the side

    PCB-VO(M)622A11

  • Industrial ICP® vibration sensor,
  • With vibration velocity output
  • Measuring range 1.27 m/s,
  • Sensitivity 3.9 V/(m/s),
  • Frequency range 3 … 9,000 Hz,
  • Frequency response calibration,
  • Integrated cable, length 3 m,
    ending on cut end

    PCB-VO(M)622A01

  • Industrial ICP® vibration sensor,
  • With vibration velocity output
  • Measuring range 1.27 m/s,
  • Sensitivity 3.9 V/(m/s),
  • Frequency range 3 … 9,000 Hz,
  • Frequency response calibration,
  • 2-pin female connector above

    PCB-(M)641B07

  • Vibration transmitter with power output according to
    the RMS value of vibration speed,
  • measuring range 0 … 25.4 mm / s RMS,
  • output range 4 … 20 mA,
  • frequency range 1 … 1.000 Hz,
  • 2 Pin socket top

    PCB-EX646B71

  • Vibrationstransmitter mit Stromausgang entsprechend
    dem Effektivwert der Schwingbeschleunigung,
  • Mit ATEX-/CSA-Zulassung,
  • Messbereich 0 … 10 g RMS,
  • Ausgangsbereich 4 … 20 mA,
  • Frequenzbereich 3 … 5.000 Hz,
  • Anschlussklemmen oben

    PCB-EX645B70

    • Vibrationstransmitter mit Stromausgang entsprechend
      dem Effektivwert der Schwingbeschleunigung,
    • Mit ATEX-/CSA-Zulassung,
    • Messbereich 0 … 5 g RMS,
    • Ausgangsbereich 4 … 20 mA,
    • Frequenzbereich 3 … 1.000 Hz,
    • Anschlussklemmen oben

    PCB-EX641B72

  • Vibrationstransmitter mit Stromausgang entsprechend
    dem Effektivwert der Schwinggeschwindigkeit,
  • Mit ATEX-/CSA-Zulassung,
  • Messbereich 0 … 50,8 mm/s RMS,
  • Ausgangsbereich 4 … 20 mA,
  • Frequenzbereich 10 … 1.000 Hz,
  • Anschlussklemmen oben
