Measuring washers (dynamic)

Measuring washers (dynamic)

Piezoelectric ring force transducers are able to measure dynamic and quasistatic pressure and impact forces (with suitable pretension also tensile forces) with rise times smaller than 10 μs. Typical use is the installation as an intermediate layer between plates or machine elements. The high rigidity and robust quartz measuring elements ensure stable operation even when used industrially. Models with ICP® technology and with charge output are available.

Showing 13-24 of 30 item(s)
Sort by:
Best sellers Relevance Name, A to Z Name, Z to A
Showing 13-24 of 30 item(s)

Active filters

PCB-(M)227C
0

PCB-(M)227C

  • ICP® force measuring element,
  • Range-133 … 222 kN,
  • Sensitivity 22.5 mV / kN,
  • Frequency range 0.0003 … 4,000 Hz,
  • 10-32 female connector on the side
      • PCB-(M)211B
      0

      PCB-(M)211B

    • Force measuring washer with charge output,
    • Measuring range 22.2 kN,
    • Sensitivity 4.05 pC/N,.
    • Upper frequency limit 90,000 Hz,.
    • 10-32 socket side
        • PCB-(M)213B
        0

        PCB-(M)213B

        • Force measuring washer with charge output,
        • Measuring range 89 kN,
        • Sensitivity 4.05 pC/N,.
        • Upper cutoff frequency?60.000 Hz.
        • 10-32 socket side
          PCB-(M)214B
          0

          PCB-(M)214B

        • Force measuring washer with charge output,
        • Measuring range 178 kN,
        • Sensitivity 4.05 pC/N,.
        • Upper frequency limit 55,000 Hz,.
        • 10-32 socket side
            • PCB-201B01
            0

            PCB-201B01

          • ICP® power measurement washer,
          • Measuring range 44.5 N,
          • Sensitivity 112 mV / N,
          • Frequency range 0.01 … 90,000 Hz,
          • 10-32 female connector on the side
              • PCB-(M)215B
              0

              PCB-(M)215B

            • Force measuring washer with charge output,
            • Measuring range 267 kN,
            • Sensitivity 4.05 pC/N,.
            • Upper frequency limit 50,000 Hz,.
            • 10-32 socket side
                • PCB-201B02
                2

                PCB-201B02

              • ICP® power measurement washer,
              • Measuring range 445 N,
              • Sensitivity 11,2 µV / N,
              • Frequency range 0.006 … 90,000 Hz,
              • 10-32 female connector on the side
                  • PCB-(M)216B
                  1

                  PCB-(M)216B

                • Force measuring washer with charge output,
                • Measuring range 356 kN
                • Sensitivity 4.05 pC/N,.
                • Upper frequency limit 40,000 Hz,.
                • 10-32 socket side
                    • PCB-201B03
                    1

                    PCB-201B03

                  • ICP® power measurement washer,
                  • Measuring range 2.224 N,
                  • Sensitivity 2,2 mV / N,
                  • Frequency range 0.002 … 90,000 Hz,
                  • 10-32 female connector on the side
                      • PCB-(M)221B01
                      0

                      PCB-(M)221B01

                    • ICP® force measuring element,
                    • Measuring range 44.5 N,
                    • Sensitivity 112 mV / N,
                    • Frequency range 0.01 … 15,000 Hz,
                    • 10-32 female connector on the side
                        • PCB-201B04
                        0

                        PCB-201B04

                      • ICP® power measurement washer,
                      • Measuring range 4.448 N,
                      • Sensitivity 1,1 mV / N,
                      • Frequency range 0.001 … 90,000 Hz,
                      • 10-32 female connector on the side
                          • PCB-(M)221B02
                          1

                          PCB-(M)221B02

                        • ICP® force measuring element,
                        • Measuring range 445 N,
                        • Sensitivity 11,2 µV / N,
                        • Frequency range 0.006 … 15,000 Hz,
                        • 10-32 female connector on the side
