Triaxial acceleration sensors-

Triaxial Acceleration Sensors

.

Showing 145-151 of 151 item(s)
Sort by:
Best sellers Relevance Name, A to Z Name, Z to A
Showing 145-151 of 151 item(s)

Active filters

PCB-3713B1210G
0

PCB-3713B1210G

  • Triaxial MEMS accelerometer,
  • Suitable for measuring static accelerations,
  • Measuring range 10 g,
  • Sensitivity200 mV / g,
  • Frequency range 0 … 1,000 Hz,
  • Supply voltage 6 … 30 V DC,
  • Integrated cable, length 3 m,
    ending on stripped and tinned ends
      • PCB-339A30
      0

      PCB-339A30

    • Triaxial ICP® high-temperature vibration sensor,
    • Continuous use temperature up to 163 ° C,
    • Very low temperature coefficient,
    • With built-in low-pass filter,
    • Measuring range 500 g
    • Sensitivity 10 mV / g,
    • Frequency range 2 … 8,000 Hz,
    • Weight 4 grams,
    • 4-pin mini connector side,
    • Including connection cable, length 3 m,
      ending to three BNC
        • PCB-356A03/NC
        1

        PCB-356A03/NC

        • Triaxial ICP® miniature vibration sensor,
        • Mass 1 gram,.
        • Measuring range 500 g
        • Sensitivity 10 mV / g,.
        • Frequency range 2... 8,000 Hz,
        • Integrated cable, length 1.5 m,
          ending on 4-pin female connector.
        • Without extension cable
          PCB-356A12/NC
          1

          PCB-356A12/NC

          • Triaxial ICP® miniature vibration sensor,
          • Measurement range 50 g,
          • Sensitivity 100 mV/g,
          • Frequency range 0.5... 5,000 Hz,
          • Weight 4 grams.
          • Integrated cable, length 1.5 m,
            ending on 4-pin female connector.
          • Without extension cable
            PCB-356A61/NC
            0

            PCB-356A61/NC

            • Triaxial ICP® miniature vibration sensor,
            • With built-in low-pass filter,.
            • Measuring range 500 g
            • Sensitivity 10 mV / g,.
            • Frequency range 2... 4,000 Hz,
            • Weight 4 grams.
            • Integrated cable, length 1.5 m,
              ending on 4-pin female connector.
            • Without extension cable
              PCB-356M98
              1

              PCB-356M98

            • Triaxialer ICP® vibration sensor for vacuum applications,
            • Low outgassing
            • Measuring range 5 g,
            • Sensitivity 1,000 mV / g,
            • Frequency range 0.5 … 3,000 Hz,
            • 4-pin female connector on the side
                • PCB-3713B12200G
                0

                PCB-3713B12200G

                • Triaxial MEMS accelerometer,
                • Suitable for measuring static accelerations,
                • Measuring range 200 g
                • Sensitivity 10 mV / g,
                • Frequency range 0 … 850 Hz,
                • Supply voltage 6 … 30 V DC,
                • Integrated cable, length 3 m, ending on stripped and tinned ends
