List of products by brand PCB Piezotronics

PCB Piezotronics was founded in 1967 as a manufacturer of piezoelectric quartz sensors, accelerometers, and associated electronics for the measurement of dynamic pressure, force, and vibration. The unique expertise of the company was the incorporation of microelectronic signal conditioning circuitry within these sensors to make them easier to use and more environmentally compatible. These ICP® sensors gained wide popularity and became the foundation for the company's success.
Subsequent growth and steady investment in facilities, machinery, and equipment permitted a constant broadening of the product offering. Measurement capabilities expanded with the addition of piezoceramic, tourmaline, capacitive, piezoresistive, and strain gage sensing technologies. Ensuing products include industrial accelerometers, DC accelerometers, load cells, torque sensors, microphones, pressure transmitters, and calibration equipment.
-> PCB Piezotronics Website
Showing 409-420 of 1981 item(s)
Sort by:
Relevance Name, A to Z Name, Z to A
Showing 409-420 of 1981 item(s)
PCB-357B34
0

PCB-357B34

High temp., ceramic shear, charge output accel., 100 pC/g, 3k Hz, 10-32 top conn. (-95 F to +500 F)

  • Sensitivity: (±15%)100 pC/g (10.2 pC/(m/s²))
  • Measurement Range: ±150 g pk (±1470 m/s² pk)
  • Frequency Range: (+5%)3000 Hz
  • Weight: 1.60 oz (45.4 gm)
    PCB-3711F11100G
    0

    PCB-3711F11100G

    Single Axis MEMS DC accelerometer, 14 mV/g, +/-100 g, 1/4-28 4-Pin Plug

    • Sensitivity: (±3%)13.5 mV/g (1.38 mV/(m/s²))
    • Measurement Range: ±100 g pk (±981 m/s² pk)
    • Broadband Resolution: 3.5 mg rms (0.034 m/s² rms)
    • Temperature Range: -65 to +250 °F (-54.0 to +121 °C)
    • Frequency Range: (±5%)0 to 1500 Hz
    • Electrical Connector: 4-Pin (4-Pin)
      PCB-3711F122G/006DZ
      0

      PCB-3711F122G/006DZ

      MEMS DC ACCEL, 3711F122G/006DZ

      • Sensitivity: (±3%)675 mV/g (68.8 mV/(m/s²))
      • Measurement Range: ±2 g pk (±19.6 m/s² pk)
      • Broadband Resolution: 0.1 mg rms (0.001 m/s² rms)
      • Temperature Range: -65 to +250 °F (-54.0 to +121 °C)
      • Frequency Range: (±5%)0 to 250 Hz
      • Electrical Connector: Integral Cable (Integral Cable)
        PCB-3711F122G/050DZ
        0

        PCB-3711F122G/050DZ

        MEMS DC ACCEL, 3711F122G/050DZ

        • Sensitivity: (±3%)675 mV/g (68.8 mV/(m/s²))
        • Measurement Range: ±2 g pk (±19.6 m/s² pk)
        • Broadband Resolution: 0.1 mg rms (0.001 m/s² rms)
        • Temperature Range: -65 to +250 °F (-54.0 to +121 °C)
        • Frequency Range: (±5%)0 to 250 Hz
        • Electrical Connector: Integral Cable (Integral Cable)
          PCB-3711F1250G/020DZ
          0

          PCB-3711F1250G/020DZ

          MEMS DC ACCEL, 3711F1250G/020DZ

          • Sensitivity: (±3%)27 mV/g (2.8 mV/(m/s²))
          • Measurement Range: ±50 g pk (±490 m/s² pk)
          • Broadband Resolution: 1.5 mg rms (0.015 m/s² rms)
          • Temperature Range: -65 to +250 °F (-54.0 to +121 °C)
          • Frequency Range: (±5%)0 to 1500 Hz
          • Electrical Connector: Integral Cable (Integral Cable)
            PCB-3713F11100G
            0

            PCB-3713F11100G

            Triaxial MEMS DC accelerometer, 13 mV/g, 100 g, 9-pin socket

            • Sensitivity: (±3%)13.5 mV/g (1.38 mV/(m/s²))
            • Measurement Range: ±100 g pk (±981 m/s² pk)
            • Electrical Connector: 9-Pin (9-Pin)
            • Weight: 0.6 oz (17.3 gm)
              PCB-3713F11200G
              0

              PCB-3713F11200G

              Triaxial MEMS DC accelerometer, 7 mV/g, 200 g, 9-pin socket

              • Sensitivity: (±3%)6.75 mV/g (0.69 mV/(m/s²))
              • Measurement Range: ±200 g pk (±1962.0 m/s² pk)
              • Electrical Connector: 9-Pin (9-Pin)
              • Weight: 0.6 oz (17.3 gm)
                PCB-3713F112G/ACS-177T
                0

                PCB-3713F112G/ACS-177T

                Triaxial MEMS DC accelerometer, 675 mV/g, 2 g, 9-pin socket, special static and dynamic calibration supplied for each axis

                • Sensitivity: (±3%)675 mV/g (68.8 mV/(m/s²))
                • Measurement Range: ±2 g pk (±19.6 m/s² pk)
                • Electrical Connector: 9-Pin (9-Pin)
                • Weight: 0.6 oz (17.3 gm)
                  PCB-3713F1150G
                  0

                  PCB-3713F1150G

                  Platinum Stock Products; Triaxial MEMS DC accelerometer, 27 mV/g, 50 g, 9-pin socket

                  • Sensitivity: (±3%)27 mV/g (2.8 mV/(m/s²))
                  • Measurement Range: ±50 g pk (±490 m/s² pk)
                  • Electrical Connector: 9-Pin (9-Pin)
                  • Weight: 0.6 oz (17.3 gm)
                    PCB-3713F12100G
                    0

                    PCB-3713F12100G

                    Triaxial MEMS DC accelerometer, 14 mV/g, 100 g, 10 ft integral cable

                    • Sensitivity: (±3%)13.5 mV/g (1.38 mV/(m/s²))
                    • Measurement Range: ±100 g pk (±981 m/s² pk)
                    • Electrical Connector: Integral Cable (Integral Cable)
                    • Weight: 4.2 oz (119 gm)
                      PCB-3713F12200G
                      0

                      PCB-3713F12200G

                      Triaxial MEMS DC accelerometer, 7 mV/g, 200 g, 10 ft integral cable

                      • Sensitivity: (±3%)6.75 mV/g (0.69 mV/(m/s²))
                      • Measurement Range: ±200 g pk (±1962.0 m/s² pk)
                      • Electrical Connector: Integral Cable (Integral Cable)
                      • Weight: 4.2 oz (119 gm)
                        PCB-3713F1250G
                        0

                        PCB-3713F1250G

                        Triaxial MEMS DC accelerometer, 27 mV/g, 50 g, 10 ft integral cable

                        • Sensitivity: (±3%)27 mV/g (2.8 mV/(m/s²))
                        • Measurement Range: ±50 g pk (±490 m/s² pk)
                        • Electrical Connector: Integral Cable (Integral Cable)
                        • Weight: 4.2 oz (119 gm)
