List of products by brand PCB Piezotronics

PCB Piezotronics was founded in 1967 as a manufacturer of piezoelectric quartz sensors, accelerometers, and associated electronics for the measurement of dynamic pressure, force, and vibration. The unique expertise of the company was the incorporation of microelectronic signal conditioning circuitry within these sensors to make them easier to use and more environmentally compatible. These ICP® sensors gained wide popularity and became the foundation for the company's success.

Subsequent growth and steady investment in facilities, machinery, and equipment permitted a constant broadening of the product offering. Measurement capabilities expanded with the addition of piezoceramic, tourmaline, capacitive, piezoresistive, and strain gage sensing technologies. Ensuing products include industrial accelerometers, DC accelerometers, load cells, torque sensors, microphones, pressure transmitters, and calibration equipment.

-> PCB Piezotronics Website

Showing 313-324 of 1981 item(s)

Sort by:

Showing 313-324 of 1981 item(s)

PCB-113B22PBO

High frequency ICP® pressure sensor placebo version of Model 113B22

PCB-118A07

Ballistic shot shell pressure sensor, 15k psi, 0.28 pC/psi, 3/8-24 integral mtg

Measurement Range: 15 kpsi (103400 kPa)
Sensitivity: (±15%)0.28 pC/psi (0.041 pC/kPa)
Sensing Element: Quartz
Temperature Range: -50 to +325 °F (-46 to +163 °C)
Electrical Connector: 10-32 Coaxial Jack
Weight: 0.52 oz (14.6 gm)

PCB-1203-11A/084A100

PCB L&T load cell, low profile, 500 lbf rated capacity, 50% overload protection, 2mV/V output 5/18 UNF female thread, PTO2E connector, with mounting base

PCB-1203-12A/084A100

PCB L&T load cell, low profile, 1000 lbf rated capacity, 50% overload protection, 2mV/V output 5/8-18 UNF-2B thread, PTO2E-10-6P connector, with mounting base.

PCB-1203-13A/084A100

PCB L&T load cell, low profile, 2000 lbf rated capacity, 50% overload protection, 2mV/V output 5/8-18 UNF-2B thread, PTO2E-10-6P connector with mounting base.

PCB-1203-14A/084A100

PCB L&T load cell, low profile, 5000 lbf rated capacity, 50% overload protection, 4.0mV/V output 5/8-18 UNF-2B thread, PTO2E-10-6P connector, with mounting base.

PCB-1203-15A/084A100

PCB L&T load cell, low profile, 10,000 lbf rated capacity, 50% overload protection, 4mV/V output 5/8-18 UNF-2B thread, PTO2E-10-6P connector, with mounting base.

PCB-1204-12A/084A101

PCB L&T load cell, low profile, 25,000 lbf rated capacity, 50% overload protection, 4.0mV/V output 1 1/4-12 UNF thread, PTO2E-10-6P connector with mounting base

PCB-1204-13A/084A101

PCB L&T load cell, low profile, 50,000 lbf rated capacity, 50% overload protection, 4.0mV/V output 1 1/4-12 UNF thread, PTO2E-10-6P connector with mounting base.

PCB-121A41

Intrinsic safe ICP® pressure sensor, 100 psi, 50 mV/psi, case isolated, 2-pin connector, temp to 250F

Measurement Range: 100 psi (689.5 kPa)
Sensitivity: (±15%)50 mV/psi (7.25 mV/kPa)
Low Frequency Response: (-5%)0.5 Hz
Resonant Frequency: >=60 kHz (>=60 kHz)
Electrical Connector: 2-Pin MIL-C-5015
Weight: 2.7 oz (75.6 gm)

PCB-121A45

Intrinsic safe ICP® pressure sensor, 500 psi, 10 mV/psi, case isolated, 2-pin connector, temp to 250F

Measurement Range: 500 psi (3447 kPa)
Sensitivity: (±15%)10 mV/psi (1.45 mV/kPa)
Low Frequency Response: (-5%)0.5 Hz
Resonant Frequency: >=60 kHz (>=60 kHz)
Electrical Connector: 2-Pin MIL-C-5015
Weight: 2.7 oz (75.6 gm)

PCB-123B22

Rocket motor ICP® pressure sensor 3000 psi 1mV/psi Helium bleed water-cooled (replaceable tubes)

This new sensor replaces Model 123A22. Model 123B22 features water cooling tubes that may be replaced on site without returning the entire sensor back to PCB for service.

Measurement Range: 3000 psi (20685 kPa)
Sensitivity: (±15%)1.0 mV/psi (0.145 mV/kPa)
Low Frequency Response: (-5%)0.001 Hz
Resonant Frequency: >=25 kHz (>=25 kHz)
Electrical Connector: Integral Cable
Weight: 4.59 oz (130 gm)
